Binary Search Tree in Go

tech · Nov 12, 2020 · ~12 min
Photo by @danfreemanphoto on Unsplash
Photo by @danfreemanphoto on Unsplash

So long since I learned to create BST back then at university. I feel like wanna revisit the BST things, so I make this post. BST is not that scary. You only need to create a tree without duplicated value on each node, then the less valuable nodes go to the left, and then the rest of the nodes go to the right or vice-versa. In this post, I’ll make a BST in Go Language with less valuable nodes of integer go to the left. I assume you have a basic knowledge of Go Language and tree data structure.

Directory Structure

1
2
3
4
5
6
7

$ tree
.
├── bst
│   ├── node.go
│   └── tree.go
├── go.mod
└── main.go

I used tree command to list down the directory structure (no pun intended).

Code

Let’s make a node struct first inside the node.go file.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24

type node struct {
  value       int
  left, right *node
}

func newNode(value int) *node {
  return &node{
    value: val,
    left:  nil,
    right: nil,
  }
}

func (n *node) Value() int {
  return n.value
}

func (n *node) Left() *node {
  return n.left
}

func (n *node) Right() *node {
  return n.right
}

I make it unexported so user can’t use node struct directly to avoid data mutability and give it some getter functions.

And then make binarySearchTree struct inside the tree.go file to wrap the usage of the node. It stores pointer of node struct as a root so we can keep track the root fo the tree.

1
2
3
4
5
6
7

type binarySearchTree struct {
  root *node
}

func New() *binarySearchTree {
  return &binarySearchTree{}
}

With current code, we can create the BST like this in main function.

1
2
3

func main() {
  tree := bst.New()
}

Now we want to give the tree some functionalities such as insert, find, traverse, and remove. Let’s go with insert first. The pseudo-code will be like this.

1
2
3
4

If there's no node, then create a new node.
If a node with same value is already exists inside the tree, returns error.
If the value is greater than current node's value, then insert to the right.
If the value is less than current node's value, then insert to the left.

We’ll make the function recursive and not directly change the tree value. So if there’s happened to be an error, the tree remains the same.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33

func insertNode(node *node, val int) (*node, error) {
  // if there's no node, create one
  if node == nil {
    return newNode(val), nil
  }

  if node.value == val {
    // if there's duplicated node returns error
    return nil, ErrDuplicatedNode
  }

  if val > node.value {
    // if value is greater than current node's value, insert to the right
    right, err := insertNode(node.right, val)

    if err != nil {
      return nil, err
    }

    node.right = right
  } else if val < node.value {
    // if value is less than current node's value, insert to the left
    left, err := insertNode(node.left, val)

    if err != nil {
      return nil, err
    }

    node.left = left
  }

  return node, nil
}

Let’s expose the function to the user via the binarySearchTree struct.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11

func (tree *binarySearchTree) Insert(val int) error {
  // always start insert from the root
  root, err := insertNode(tree.root, val)

  if err != nil {
    return err
  }

  tree.root = root
  return nil
}

To check whether the value we entered is in the correct position, then we create the traverse function first. There are 3 ways to traverse the tree, pre-order, in-order, and post-order. Here’s the difference:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14

# pre-order
1. print current value
2. go recursively to the left
3. go recursively to the right

# in-order
1. go recursively to the left
2. print current value
3. go recursively to the right

# post-order
1. go recursively to the left
2. go recursively to the right
3. print current value

To remember it easily, remember when you need to print the current value. if pre then print first, if post then print at the end, otherwise print in the middle. we’re gonna make in order traverse, because it will go recursively to the left first and then print the value which means in our case it will print from least valuable nodes to the greatest.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15

func traverse(node *node) {
  // exit condition
  if node == nil {
    return
  }

  traverse(node.left)
  fmt.Println(node.value)
  traverse(node.right)
}

func (tree *binarySearchTree) Traverse() {
  // traverse from the root
  traverse(tree.root)
}

Let’s check our code first.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13

func main() {
  tree := bst.New()

  tree.Insert(23)
  tree.Insert(10)
  tree.Insert(15)
  tree.Insert(20)
  tree.Insert(2)
  tree.Insert(25)
  tree.Insert(50)

  tree.Traverse() // 2 10 15 20 23 25 50
}

Now that you find your traverse results sorted, let’s move to the find function. To find a specific node you don’t have to go around the whole tree, you need to know that BST can route to a specific node by checking the node value. Just like the insert function, we only need to go to the left if the node value we are looking for is less than the current node and to the right, if the node value is greater.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27

func findNode(node *node, val int) *node {
  if node == nil {
    return nil
  }

  // if the node is found, return the node
  if node.value == val {
    return node
  }

  // if value is greater than current node's value, search recursively to the right
  if val > node.value  {
    return findNode(node.right, val)
  }

  // if value is less than current node's value, search recursively to the left
  if val < node.value {
    return findNode(node.left, val)
  }

  return nil
}

func (tree *binarySearchTree) Find(val int) *node {
  // as always, search from the root
  return findNode(tree.root, val)
}

Now we return the specified node if there is a node with given value otherwise, we return nil. Since we encapsulate the node attributes and leave the user only with the Getter function, there is no need to worry about data mutability.

Now let’s move to the remove function. Just like insert and find function, we need to locate the position of the node first and then do the deletion. There are 3 rules to remove a node from its tree.

1
2
3

If the node has no child, then Simply make it nil
If the node has 1 child, then move the child to the node position.
If the node has 2 children, then find the successor and move the successor to the node position.

To find the successor of the node there are 2 ways

1
2
3

Find the least valueable node from the right child of the node
OR
Find the greatest valueable node from the left child of the node

I will use the first approach, find the least valuable node of the right child node. To find the least valuable node from the current node, you only need to go to the leftmost node. And to find the most valuable node of the current node, just go to the rightmost node.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65

func least(node *node) *node {
  if node == nil {
    return nil
  }

  if node.left == nil {
    return node
  }

  return least(node.left)
}

func removeNode(node *node, val int) (*node, error) {
  if node == nil {
    return nil, ErrNodeNotFound
  }

  if val > node.value {
    right, err := removeNode(node.right, val)
    if err != nil {
      return nil, err
    }

    node.right = right
  } else if val < node.value {
    left, err := removeNode(node.left, val)
    if err != nil {
      return nil, err
    }

    node.left = left
  } else {
    if node.left != nil && node.right != nil {
      // has 2 children

      // find the successor
      successor := least(node.right)
      value := successor.value

      // remove the successor
      right, err := removeNode(node.right, value)
      if err != nil {
        return nil, err
      }
      node.right = right

      // copy the successor value to the current node
      node.value = value
    } else if node.left != nil || node.right != nil {
      // has 1 child
      // move the child position to the current node
      if node.left != nil {
        node = node.left
      } else {
        node = node.right
      }
    } else if node.left == nil && node.right == nil {
      // has no child
      // simply remove the node
      node = nil
    }
  }

  return node, nil
}

That’s all, folks. If I curate the code it will be like this.

node.go

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170

package bst

import (
  "errors"
  "fmt"
)

var (
  ErrDuplicatedNode error = errors.New("bst: found duplicated value on tree")
  ErrNodeNotFound   error = errors.New("bst: node not found")
)

type node struct {
  value       int
  left, right *node
}

func (n *node) Value() int {
  return n.value
}

func (n *node) Left() *node {
  return n.left
}

func (n *node) Right() *node {
  return n.right
}

func newNode(val int) *node {
  return &node{
    value: val,
    left:  nil,
    right: nil,
  }
}

func insertNode(node *node, val int) (*node, error) {
  // if there's no node, create one
  if node == nil {
    return newNode(val), nil
  }

  if node.value == val {
    // if there's duplicated node returns error
    return nil, ErrDuplicatedNode
  }

  if val > node.value {
    // if value is greater than current node's value, insert to the right
    right, err := insertNode(node.right, val)

    if err != nil {
      return nil, err
    }

    node.right = right
  } else if val < node.value {
    // if value is less than current node's value, insert to the left
    left, err := insertNode(node.left, val)

    if err != nil {
      return nil, err
    }

    node.left = left
  }

  return node, nil
}

func removeNode(node *node, val int) (*node, error) {
  if node == nil {
    return nil, ErrNodeNotFound
  }

  if val > node.value {
    right, err := removeNode(node.right, val)
    if err != nil {
      return nil, err
    }

    node.right = right
  } else if val < node.value {
    left, err := removeNode(node.left, val)
    if err != nil {
      return nil, err
    }

    node.left = left
  } else {
    if node.left != nil && node.right != nil {
      // has 2 children

      // find the successor
      successor := least(node.right)
      value := successor.value

      // remove the successor
      right, err := removeNode(node.right, value)
      if err != nil {
        return nil, err
      }
      node.right = right

      // copy the successor value to the current node
      node.value = value
    } else if node.left != nil || node.right != nil {
      // has 1 child
      // move the child position to the current node
      if node.left != nil {
        node = node.left
      } else {
        node = node.right
      }
    } else if node.left == nil && node.right == nil {
      // has no child
      // simply remove the node
      node = nil
    }
  }

  return node, nil
}

func findNode(node *node, val int) *node {
  if node == nil {
    return nil
  }

  // if the node is found, return the node
  if node.value == val {
    return node
  }

  // if value is greater than current node's value, search recursively to the right
  if val > node.value  {
    return findNode(node.right, val)
  }

  // if value is less than current node's value, search recursively to the left
  if val < node.value {
    return findNode(node.left, val)
  }

  return nil
}

func least(node *node) *node {
  if node == nil {
    return nil
  }

  if node.left == nil {
    return node
  }

  return least(node.left)
}

func traverse(node *node) {
  // exit condition
  if node == nil {
    return
  }

  traverse(node.left)
  fmt.Println(node.value)
  traverse(node.right)
}

tree.go

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42

package bst

type binarySearchTree struct {
  root *node
}

func New() *binarySearchTree {
  return &binarySearchTree{}
}

func (tree *binarySearchTree) Insert(val int) error {
  // always start insert from the root
  root, err := insertNode(tree.root, val)

  if err != nil {
    return err
  }

  tree.root = root
  return nil
}

func (tree *binarySearchTree) Remove(val int) error {
  root, err := removeNode(tree.root, val)

  if err != nil {
    return err
  }

  tree.root = root
  return nil
}

func (tree *binarySearchTree) Find(val int) *node {
  // as always, search from the root
  return findNode(tree.root, val)
}

func (tree *binarySearchTree) Traverse() {
  // traverse from the root
  traverse(tree.root)
}

main.go

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25

package main

import (
  "learn/bst"
)

func main() {
  tree := bst.New()

  tree.Insert(23)
  tree.Insert(10)
  tree.Insert(15)

  tree.Remove(10)

  tree.Insert(20)
  tree.Insert(2)
  tree.Insert(25)

  tree.Remove(25)
  tree.Remove(23)
  tree.Insert(50)

  tree.Traverse() // 2 15 20 50
}

Thank you for reading!

· · ·

Love This Content?

Any kind of supports is greatly appreciated! Kindly support me via Bitcoin, Ko-fi, Trakteer, or just continue to read another content. You can write a response via Webmention and let me know the URL via Telegraph.
